Characteristics of pressed wire rope slings
High working load limit
Perfect pressed shape
Excellent cauterization resistance
Saving wire rope cost
Ensure the exact length
Advanced technics and efficiency
Good solution to rigging works with limited working space
Model | CLH-200 | CLH-300 | CLH-500 | CLH-600 | CLH-800 | CLH-1000 | CLH-1500 | |
(MAX.Force) | KN | 2000 | 3000 | 5000 | 6000 | 8000 | 10000 | 15000 |
MAX.dia.in one pressing) | mm | Ф20 | Ф28 | Ф38 | Ф42 | Ф48 | Ф52 | Ф62 |
(MAX.dia.with multi bite pressing) | mm | Ф22 | Ф32 | Ф40 | Ф44 | Ф50 | Ф56 | Ф65 |
(MAX.piston movement) | mm | 80 | 140 | 140 | 180 | 180 | 220 | 220 |
(Piston working movement) | mm | 50 | 60 | 90 | 100 | 110 | 130 | 190 |
(MAX.working pressure) | Mpa | 28 | 28 | 45 | 28 | 40 | 28 | 28 |
(The up speed of piston) | mm/sec | 4.4 | 5.3 | 5.3 | 4.5 | 3.64 | 3.1 | 2.5 |
(The down speed of piston) | mm/sec | 6 | 8.8 | 8.8 | 8.7 | 7 | 6.4 | 5.1 |
MAX.force(KN) | 6000 |
MAX.dia.in one pressing(mm) | φ42 |
MAX.dia.with multi bite pressing(mm) | φ44 |
MAX.piston movement(mm) | 180 |
Piston working movement(mm) | 100 |
MAX.working pressure(Mpa) | 28 |
The up speed of piston(mm/sec) | 4.5 |
The down speed of piston(mm/sec) | 8.7 |
Color | Blue、Green |
